♦♦How to set up the program?
The display panel and key function list:
In the initial state of power on, the digital tube displays: XXXL, the XX on the left is the running speed of the dreamcolor lights on both sides of the stairs, 01-99, 01 is the fastest, 99 is the slowest, the X on the right is the color, 1 is white, The corresponding colors of 2-7 are red green blue yellow purple green.
Method of adjusting parameters by keys: In the initial XXXL display state,press the button “SET” into the setting parameter state, adjust the state value by pressing the two buttons of “SP- SP+”, then press the button “SET” again getting into the next menu adjustment state, the displayed state lists are as follows:
LXXX 010-800 Set The Pixel number of segment length of dreamcolor light strips on both sides of stairs, the maximum number is 800, press two buttons of “SP-SP+” to adjust, after finishing, continue to press “SET” getting into the next step,LPXX 01-07 is for the side panel light strip color is also adjusted by “SP- and SP+”, after finishing, then press SET getting into the next setting, 01 white 02 red 03 green 04 blue 05 yellow 06 purple 07 green LHXX 01-99 is for side dreamcolor light strip flashing speed,FXXX 010-800 Set the Number of stair step white light strips,
maximum 800 stairs FPXX stairs’ light effect, there is only 1 transition effect at the moment FHXX the speed of the stair white light turns on/off step by step
EEXX 01-99 seconds，adjusts the delay time when people walk through and stay on. When the delay time is up, the side panel light strip and stair light strip are extinguished gradually.
After finishing the adjustment of the parameters, press the “SET” button one last time, the parameter display will return to the XXXL display state, and it will automatically save the set parameters to the control system, the next time it will work according to the newly set parameters.
